Cooling performance up to 600 W/cm2 with ultra-flat ceramic liquid Heat-Sinks

CeramCool^® Multi-K

• Heat-sinks 3 mm in height for extremely flat cooling systems.
• Cooling performance of up to 600 W/cm² over the entire surface
• Ideal for silver sintering technology thanks to its high mechanical stability

• Standard dimensions: 100 x 60 x 3 mm
• Length: variable up to max. 150 mm

Al₂O₃ design

• R_th: 0.007 K/W @ L=120 mm
• R'_th: 0.4 Kcm²/W @ 50 l/h

AlN design

• R_th: 0.0022 K/W @ L=120 mm
• R'_th: 0.133 Kcm²/W @ 50 l/min

Connections

Different connection methods available depending on customer requirements
